Cutting speed | 5-220(m/min) |
Max web width | 320mm |
Max unwinding diameter | 600mm |
Max rewinding diameter | 500mm |
Min. width after slitting | 20mm |
Slitting precision | 0.2mm |
Total power | 1.5kw |
Power supply voltage | 220V or 380V as your request |
Overall diameters | 1.2 (L)*0.9(W)*1.4 (H) |
Machine weight | (about)500kg |
þHave web guide system
þHave meter counting
þFrequency inverter control system
þUse 3 inch air shaft(Φ76mm) for unwind (also can make according to your request)
þUse 2 pcs 3 inch air shaft
þWith auto taper tension control
þHave one wasting fan
þHave 8 sets knife
